Vivitek

DU6198Z

A lightweight projector with high brightness for large venues

Overview

Key Features

Specifications

Documentation

Accessories

Overview

Key Features

Specifications

Documentation

Accessories

Overview

The newly designed solid-state laser phosphor DU6198Z of projector weigh only 26 kg and offers extreme versatility in performance and functionality, making them ideal for large venues. This DU6198Z delivers incredible brightness 8,500 lumens with a 3,000,000:1 dynamic contrast ratio, WUXGA resolution, HDMI 2.0 support, and HDR 10 optimization for precise and natural colors. With a user-friendly projector control tool and support for nine motorized lenses, the DU6198Z is specifically designed to handle portrait mode installation and 360° operation for projection from virtually any angle.

Key Features

Brightness and Color Performance

The DU6198Z features high brightness and uses Vivitek’s advanced color technology to deliver a perfect image display.

IP6X Optical Engine Certified Design

The DU6198Z complies with high standards for protection against dust, ensuring consistent brightness over time.

PJ-Control Tool

Vivitek’s PJ-Control software is a tool for controlling Vivitek projectors. It can be used to manage multiple projectors, helping users control viewing options, settings, and scheduling, and it also allows for the adjustment of display features over a network.

Optional Motorized Lens Support

The DU6198Z is perfect for large venues with support for up to nine motorized lenses. A quick lens release button offers a simple and secure way to change lenses.

Flexible Installation

Support for 360° operation means no limitation on projection angle, vertical / horizontal keystone, and 4-corner geometric adjustment, allowing for almost unlimited mounting options.

Constant Brightness

With built-in color sensor technology, this series of projectors can automatically adjust the light to maintain constant and stable brightness over a long period of time.

24/7 Operation

Vivitek’s laser light source can be operated for 30,000 hours in “Eco Mode” and is approved for 24/7 operation. It delivers high stability and reliability for commercial applications.

Specifications

Display

Projection System

1-Chip DLP™ 0.67 inch

Resolution

WUXGA (1920 x 1200)

Light Source

Laser

Optics

Brightness

8,500 lm

Brightness Uniformity

90%

Contrast Ratio

1,300:1 (Native) / 20,000:1 (Dynamic) / 3,000,000:1 (Full On/Off)

Light Source Life

20,000 hrs (Normal)

Lens Type

Optional (D88/D86 Lenses)

Zoom Ratio

Base On Lens Spec

Lens Throw Ratio

D88 Lenses: 0.38:1 / 0.76:1 / 0.75~0.93:1 / 1.25~1.79:1 / 1.73~2.27:1 / 2.22~3.67:1 / 3.58~5.38:1 / 5.31~8.26:1

Lens Shift - Horizontal (Full Image Width)

+5% ~ -5%

Offset (Full Image Width)

+55% ~ -15%

Geometry Adjustment

Keystone Correction

Yes (H/V)

Four Corner Adjustment

Yes

I/O Terminal

HDMI

2.0 x2

DisplayPort

N/A

SDI

N/A

DVI-D

YPbPr

N/A

D-Sub

In x1 / Out x1

3D Sync

In x1 / Out x1

RJ45

HDBaseT x1, LAN x1

RS-232

In x1 / Out x1

Wire Remote

In x1 / Out x1

Speaker

N/A

USB

Type A (Power Only 5V/2A) x1 ／ Type B (Service) x1

12V Trigger (mini Jack)

5 BNC

Audio

Audio-In (RCA) x1 ／ MIC-Out (Mini-Jack) x1

System

Power Supply

AC 100-240V 50/60Hz

Power Consumption ±5%

920W (Normal) / 660W (Eco)

Standby Power

< 0.5W (Network Off)／< 2.0W( Network On)

Acoustic Noise ±5%

Normal 38dB / Eco 35dB

Dimension ±2%

580 x 500 x 205 mm

Weight ±1kg

26.4 kg

3D Display

Active / Passive

24x7 Operation

Yes

Dust Proof*4

IP5X

Operation Oreinetation

360˚ free installation

Operation Environment

Temp. 5~40˚C / Humidity10~85%

Storage Environment

Temp. -10~60˚C / Humidity 5~95%

Documentation

Flyer

Download

User Manual

Download

Accessories

VWD-01

VWD-01 is a Full HD wireless display receiver accessory for support all of Vivitek projectors

Download

D88-UST01B

Throw ratio: 0.38:1

D86-0711

Throw ratio: 0.77 – 1.1: 1

D86-1113

Throw ratio: 1.1 – 1.3: 1

D86-1216

Throw ratio: 1.25 – 1.60: 1

D86-1519

Throw ratio: 1.54 – 1.93: 1

D86-1929

Throw ratio: 1.93 – 2.9: 1

D88-SMLZ01

Throw ratio: 2.22~3.67: 1

D88-LOZ101

Throw ratio: 3.58~5.38 : 1

D88-LOZ201

Throw ratio: 5.31~8.26: 1
