BK753i
Collaborative Touch Panel Solution
Overview
Key Features
Specifications
Documentation
Accessories
Overview
Key Features
Specifications
Documentation
Accessories
Overview
The NovoTouch BK3 series is a 4K-UHD collaborative touch display solution that is perfect for education. This series is available for 65" , 75" , and 86” different display sizes with combining digital whiteboard, wireless collaboration, and digital signage functionalities. BK3 series supports interactive IR touch technology and anti palm for the best touch and viewing experience.
Key Features
Key Features
The BK3 series is TÜV Rheinlan Certified which can protect your eyes with low Blue Light & Flicker Free for the best viewing experience.
The BK3 series features 65”/75”/86” display size with 4K Ultra-HD (3,840 x 2,160) resolution to deliver outstanding details and stunning visuals.
Specifications
Specifications
Hardware
Screen Size
75"
Resolution
4K
Brightness cd/m² (typ.)
400
Dynamic Contrast Ratio
1200：1
Installation Orientation
Landscape
Viewing Angle(H/V)
178° / 178°
Daily Operation
16/7
Memory
DDR4 8G
Storage
eMMC 64GB
Speaker
18W x2 (stereo)
Wireless
WiFi 6 & BlueTooth 5.2
Interactivity
Touch 40 points & Writing 10 points
Internet
LAN (x1)
Low Blue Light & Flicker Free
Yes
OPS expansion
Standard Intel 80pin (option)
USB C
x1,(front panel) 15W charging, display input
Power Supply
AC 100 - 240V, 50/60Hz
Power Consumption
130.5W (min.)
Dimension
1484.5 x 90 x 908 mm
Weight
39kg
Software
OS Version
Android™ v14.0
Remote Management Tool
Yes
Google Play Store
Yes
NovoConnect Stage
Yes ( w intel OPS)
Software - Wireless Collaboration
Wireless Presentation
Yes (2 splits)
Screen Recording
Yes
On-Screen Annotation
Yes
Whiteboard
Yes
Miracast
NA
Google Cast
Yes
AirPlay
Yes
BYOM
NA
USB plug-and-play
Yes ( w LauncherPlus)
Software - Digital Signage
Creating / Edit Playlist
Yes
Publish Content
Yes
Scheduling Playback
Yes
Content Management System
Yes
Screen Orientation
Yes
Announced Board
Yes
Social Media (Twitter, Instagram, Facebook)
Yes
YouTube / IP Streaming
Yes
Calendar
Yes
